Recommended Preparation

• Microfiber cloth and glass-safe cleaner
• Plastic trim tool
• Cable clips or approved adhesive retainers
• Vehicle power outlet or compatible USB supply

Installation Sequence

1. Clean the windshield area and confirm that the selected location does not restrict the driver’s view.
2. Attach the mount temporarily, power the camera and check the live image before fixing the position.
3. Route the cable along the headliner edge and down the trim without crossing airbag deployment paths.
4. Connect the power supply, secure excess cable and verify that no wire interferes with pedals or controls.
5. Set the date, recording resolution and storage preferences, then complete a short test drive.

Recommended Preparation

• Vehicle fuse diagram
• Compatible fuse taps and replacement fuses
• Multimeter or circuit tester
• Plastic trim tool and cable ties

Installation Sequence

1. Turn off the vehicle and locate the interior fuse panel using the vehicle manual.
2. Identify suitable constant and accessory circuits only where required by the hardwire kit instructions.
3. Confirm circuit behavior with appropriate testing equipment before inserting any fuse tap.
4. Connect the ground terminal to an approved unpainted chassis grounding point.
5. Configure the low-voltage protection setting and test normal recording and parking mode operation.

Recommended Preparation

• Dashboard-safe cleaning cloth
• Mounting plate or approved dashboard mount
• Compatible power cable
• Audio connection cable when required

Installation Sequence

1. Choose a location that remains visible without obstructing the windshield, vents or vehicle controls.
2. Clean and dry the mounting area before installing the base or suction mount.
3. Secure the display, adjust its angle and confirm that it remains stable under light pressure.
4. Route the power and audio connections away from steering, shifting and climate controls.
5. Pair the phone, test audio output and adjust display brightness for daytime and nighttime use.

Recommended Preparation

• Trim removal tools
• Electrical test equipment
• Weather-resistant cable protection
• Vehicle wiring and lamp access information

Installation Sequence

1. Select a centered location with an unobstructed rear view and confirm that the mount is weather appropriate.
2. Plan a protected cable route through existing vehicle grommets whenever possible.
3. Connect the camera and reverse-trigger wire according to the product and vehicle instructions.
4. Route the video cable to the display while avoiding sharp edges, moving panels and airbag areas.
5. Test the image, orientation and parking guidelines before securing trim and finalizing the camera angle.

Recommended Preparation

• Vehicle compatibility information
• Mobile phone with required application
• Account and activation information
• Optional extension cable for recessed ports

Installation Sequence

1. Park safely, switch off the vehicle and locate the OBD-II port beneath the dashboard.
2. Inspect the port and confirm that the connected device will not restrict pedal movement or driver access.
3. Insert the device firmly without forcing the connector or twisting the port.
4. Start the vehicle if directed, open the relevant application and complete pairing or activation.
5. Review alert preferences and verify the device status after the vehicle has been restarted.

Recommended Preparation

• Vehicle outlet rating information
• Compatible charging cables
• Dashboard-safe cable retainers
• Device power requirement information

Installation Sequence

1. Review the charger input rating and confirm compatibility with the vehicle outlet.
2. Select a location that remains ventilated and does not interfere with controls or storage access.
3. Connect the charger firmly and route each device cable with sufficient slack for normal movement.
4. Avoid covering the charger or placing connected devices where heat may accumulate.
5. Connect devices individually, confirm stable charging and review the combined output limits.
